Grade: Commercial Quality–JIS 3141 SPCC, JIS 3141 SPCCT
Size: Thickness: 0.40 – 2.00mm
Grade: Drawing Quality: JIS 3141 SPCD
Size: Width: 900 – 1250mm to 1000 – 1250mm
Grade: Deep Drawing Quality–JIS 3141 SPCE, JIS 3141 SPCF
Size: Form: Coil form/ Sheet, 2400 – 6000 sheet
Grade: Extra Deep Drwaing Quality–JIS 3141 SPCG
Size: Remarks: Mild Edge, Slitted Edge, Cut to length
Grade: Other grades on request
Grade: JIS 3101 / G 3131 (SS330, SS400, SS490, SS540)
Size Thickness: 1.00 – 2.00mm to 1.00 – 15.07mm
Grade: ASTM (ASTM A36/ A572 Gr. 42/ A572 Gr. 50
Size: Width: 1000 – 2000mm to 1200 – 3000mm
Grade: DIN 17100 ( DIN 43A/ 43B/ 43C/ 50A/ 50B/ 50C / S275JR/ S235JR
Size Form: Coil form/ Sheet, 2400 – 6000 sheet
Grade: BS 4360 / 1986 EN 10025
Size: Remarks: Mild Edge, Slitted Edge, Cut to length
Grade: Width Tolernace
Width: upto 200mm: -0/+20mm || Width>-0/+25mm
Grade: AA1100/ AA1200/
Size: Width: 4′ x 8′
Thickness: 1.5mm to 10.0mm
Size Width: 2m – 3.05m
Length: 6m to 12m
Thickness: 4mm to 60mm
Grade: ASTM A36/ S275JR/ SS400
Size: Width: 1219mm x 2438mm
Thickness: 1.8mm to 10mm
Width: 1500mm x 6000mm
Thickness: 3.0mm to 10mm
Grade: AA1100/ AA1200/
Size: Width: 1219mm/ 1500mm
Thickness: 0.5mm to 3.0mm
Dimensions: DIN 10261 – 1:2000, NF A 45202 (1983)
Size: UPN 80 to UPN 400
Dimensions: BS 4 – 1: 1993
Tolerances: EN 10279 : 2000
Size: 100 x 50 x 10 to 430 x 100 x 64
Dimensions: ASTM A6 / A6M – 03
Tolerances: ASTM A6 / A6M – 03 to BS 4 ; Part 1 ; 1993
Size: W 4 x4 to W 44 x 16
Grade: BS 4 : Part 1 : 1993
Size: 152 x 152 x 23 to 356 x 406 x 634
Grade: BS 4 : Part 1 : 1993
Size: 356 x 127 x 76 to 610 x 305 x 149
Grade: PF in accordance with Eoronorm 53 – 62
Size: HE 100 AA to HE 1000M, IPE 100A to IPE 750 x 222, IPN 80 to IPN 600
Grade: ASTM A 653 / A 653 M – 07
Size: Thickness: 0.28 – 4.00mm to 0.30 – 4.00mm
Grade: CS Type A, B, C
Size: Width: 900 – 1500mm to 650 – 1500mm
Grade: FS type A, B
Size: Form: Coil form/ Sheet
Grade: DDS Type A, B
Size: Remarks: Mild Edge, Trimmed Edge, Slitted Coil, Trimmed Edge
Grade: SS Grade 33, 37, 40, 50, 55, 80
Type: Tension Levelled/ Non Tension Levelled (Full Hard) Standard Coating: Z90 (G30), Z120 (G 40), Z180 (G 60), Z275 (G 90), Z350 (G115)
Surface Finish: Regular Spangle/ Minimum Spangle/ Skinpassed
Grade: 304/ 316L/ 304L/ 430/ 310S
Size: Thickness:0.30 – 50 mm
Width: 1219/ 1250/ 1500/ 2000 mm
Coil ID: 508/ 610
Diameter: 8 to 50 mm (Metric), 0.315 to 2.00″ (Imperial)
Length: 6 to 18 m (Metric), 20 to 60′ (Imperial)
Diameter: 6 to 16 mm (Metric), 0.237 to 0.63″ (Imperial)
Length: 1.8 to 2 tons (Metric), 3970 to 4850 lbs’ (Imperial)
Grade: 304/ 316L/ 201
Size: 3 / 8″ to 6
Thickness: 1.20 – 2mm
Sch 5 – Sch 80
Grade: EN 10255 : 2004 + Ai : 2007
Size:
Grade: ASTM A53 Gr – A Schedule 40
Size: 1/2′ to 12″
Grade: ASTM A53 Gr – B Schedule 40
Size: 1/2′ to 12″
Type: Cold-Formed Welded Square Tubes
Size Range: 40 mm x 20 mm to 500 mm x 300 mm
Standard: S235 JRH/ S275 JOH/ S275 J2H/ S355 JOH/ S335 J2H
Type: Cold-Formed Welded Square Tubes
Size Range: 19 mm x 19 mm to 400 mm x 400 mm
Standard: ASTM A106/ ASTM A53 Gr. B SCH 40
Grade Specifications: JIS G3131 SPHC
Size: 4′ x 8′ x 2mm x 35 x 70 to 4′ x 8′ x 80mm x 35 x 70
Grade: Type: Plane or Serrated
Grade: Specifications:
The load-bearing bar confirms the panel size.
Size: Panel Size: 1m x 6m
Grade: ASTM A36, BS 4360 Gr. 43A or Equalent Grade
Size: Load Bearing Bar: 20mm x 3mm to 40mm x 5mm
Pitch Size: 30 x 100mm/ 40x100mm to 30 x 100mm/ 40x100mm
Grade: 201/304/316L/310S
Size: 4′ x 8′ 4′ x 10′ 5′ x 10′ 5′ x 10′ 2 Mtr. x 6 Mtr
Thickness: 0.50mm to 30mm
Grade: 201/304/316L
Size: 4′ x 8′ 4′ x 10′ 5′ x 10′
Thickness: 0.50mm to 30mm
Grade: 304/316L/201
Size: 4′ x 8′ 4′ x 10′ 5′ x 10′
Thickness: 0.50mm to 30mm
Grade: 304/316L/201
Size: 4′ x 8′ 4′ x 10′ 5′ x 10′
Thickness: 0.50mm to 30mm
Grade: 304/316L/201
Size: 4′ x 8′ 4′ x 10′ 5′ x 10′
Thickness: 0.50mm to 30mm
Grade: 304/316L/201
Size: 4′ x 8′ 4′ x 10′ 5′ x 10′
Thickness: 0.50mm to 30mm
Grade: 304/ 316L
Size Length: 3MTR, 4MTR, 6MTR
Thickness: 3mm – 50mm, 3mm – 50mm, 3mm – 50mm
Grade: 304/ 316L
Size: 20 – 100, 20 – 100
Length: 6MTR, 6MTR
Thickness: 3mm – 10mm, 3mm – 10mm
Grade: 304/ 316L
Size: 25 x 50 – 150 x 75, 25 x 50 – 150 x 75
Length: 6MTR, 6MTR
Grade: 304/ 316L
Size: 20 x 20 – 150 x 150, 20 x 20 – 150 x 150
Thickness: 1.50mm – 12mm, 1.50mm – 12mm
Grade: 304/ 316L/ 201
Size: 10 x 10 – 100 x 100, 20 x 10 – 200 x 100
Thickness: 1.20mm – 4mm, 1.20mm – 4mm
Grade: 304/ 316L/ 201
Size: 10 x 10 – 100 x 100, 20 x 10 – 200 x 100
Thickness: 1.20mm – 4mm, 1.20mm – 4mm
